Product details
Photometrics
Light Source: 19x 12 W RGBWAU LEDs
Beam Angle: 30°
Output: 12,000 lux @ 2 m @ 25° RGBW full on
PWM: 1,200Hz
LED Life: 50,000 hours
Effects
Dimming: 0~100%, 8 / 16 bit
Fade Modes: Standard, Stage, TV, Architecture, Theatre
Strobe: 1~30 Hz
Power
Input Voltages: 100~240 V AC, 50/60 Hz, 200 W
Power Connection: Seetronic® Outdoor Powerkon in/out
Control
Operational Modes: DMX, manual, auto, sound active, master / slave
Display: 4-button LCD control panel
Control Protocol: DMX512, RDM
DMX Channels: 3 / 4 / 6 / 10 / 12
Control Interface: Seetronic® 3 Pin Outdoor DMX in/out
Housing
Housing Materials: Die-cast aluminium housing, matte black finish
IP Rate: IP65
Cooling: Fanless Cooling
Dimension: 370 x 380 x 165 mm
Net Weight: 9.5 kg
Misc
Accessories Included: 2M Seetronic® Outdoor Powercon, 2M Seetronic® Outdoor Powercon Extension, 2M Seetronic® Outdoor DMX Cable
IMPORTANT: Only use the provided Outdoor DMX cable in the device’s DMX out port. Use of other cables will cause the cable to become stuck in the port, requiring the unit to be repaired.
Download the User Manual
Light Source: 19x 12 W RGBWAU LEDs
Beam Angle: 30°
Output: 12,000 lux @ 2 m @ 25° RGBW full on
PWM: 1,200Hz
LED Life: 50,000 hours
Effects
Dimming: 0~100%, 8 / 16 bit
Fade Modes: Standard, Stage, TV, Architecture, Theatre
Strobe: 1~30 Hz
Power
Input Voltages: 100~240 V AC, 50/60 Hz, 200 W
Power Connection: Seetronic® Outdoor Powerkon in/out
Control
Operational Modes: DMX, manual, auto, sound active, master / slave
Display: 4-button LCD control panel
Control Protocol: DMX512, RDM
DMX Channels: 3 / 4 / 6 / 10 / 12
Control Interface: Seetronic® 3 Pin Outdoor DMX in/out
Housing
Housing Materials: Die-cast aluminium housing, matte black finish
IP Rate: IP65
Cooling: Fanless Cooling
Dimension: 370 x 380 x 165 mm
Net Weight: 9.5 kg
Misc
Accessories Included: 2M Seetronic® Outdoor Powercon, 2M Seetronic® Outdoor Powercon Extension, 2M Seetronic® Outdoor DMX Cable
IMPORTANT: Only use the provided Outdoor DMX cable in the device’s DMX out port. Use of other cables will cause the cable to become stuck in the port, requiring the unit to be repaired.
Download the User Manual
